Blackmagic Design Micro Converter BiDirectional SDI/HDMI 12G wPSU
Blackmagic
-
₱13,600.00
- 0% 3mos BDO, BPI, UNIONBANK, HSBC ₱4,533.33/mo.
This item cannot be check out. For availability, inquiries and interested buyers, kindly chat us on our FB messenger Henry's Cameras PH or send us an email at sales@henryscameraphoto.com.
- Simultaneous SDI to HDMI & HDMI to SDI
- 1 x SD/HD/12G-SDI & 1x HDMI Input/Output
- Supports up to DCI/UHD 4K60 Video
- Blackmagic Camera Control, Tally Support
- SDI Re-Clocking/HDMI Timecode
- HDMI Copy Protection Support
- Automatic Input Signal Detection
- Embedded HDMI & SDI Input/Output
- LED Video & Power Signal Indicators
- A Power Supply Is Included
Control
| Tally Light | Yes |
Environment
| Operating Temperature | 32 to 72°F / 0 to 40°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
Format Support
| Embedded Audio | HDMI/SDI |
| Input Video Format | SDI (8/10-Bit 4:2:2 RGB, YUV) DCI 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps UHD 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps DCI 2K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps DCI 2KPsF at 25/29.97/30 fps 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1080PsF at 25/29.97/30 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps HDMI (8/10-Bit 4:2:2 RGB, YUV) DCI 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps UHD 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps |
| Output Video Format | SDI (8/10-Bit 4:2:2 RGB, YUV) DCI 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps UHD 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps DCI 2K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps DCI 2KPsF at 25/29.97/30 fps 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1080PsF at 25/29.97/30 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 480i / 525 lines at 29.97 fps 576i / 625 lines at 25 fps HDMI (8/10-Bit 4:2:2 RGB, YUV) DCI 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps UHD 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps |
Hardware
| OS Compatibility | macOS 10.15.15 or Later Windows 11.1 or Later |
Inputs / Outputs
| Audio I/O | No |
| Other I/O | 1x USB-C Firmware Input (Shared Power) |
| Video I/O | 1x BNC (12G-SDI) Female 1x HDMI (2.0) Female |
Power
| Power Consumption | Device: 5 W |
| Power I/O | 1x USB-C (4.4 to 5.2 VDC ) Input |
Standards
| HDCP Compatible | Yes: Version 2.2 |
| Video Standard Compliance | SMPTE 259M/292M/296M/424M/425M-A/425M-B |
General
| Dimension | 3.18 x 2.32 x 0.98" / 80.77 x 58.93 x 24.89 mm |
| Weight | 6.13 oz / 174 g |
| Warranty | 1 Year Warranty |
Now you can convert in both directions simultaneously! Convert SDI to HDMI and HDMI to SDI in any combination of SD, HD or Ultra HD formats all at the same time! Micro Converter BiDirectional SDI/HDMI 12G lets you simultaneously convert SDI to HDMI and HDMI to SDI in all SD, HD and Ultra HD formats up to 2160p60! Each conversion direction can be a different SD, HD or Ultra HD video standard, it’s like getting two converters in one! With multi-rate 12G-SDI input and output connections, Micro Converter BiDirectional SDI/HDMI 12G is compatible with virtually all professional broadcast equipment, including level A and B devices. It even automatically detects all SD, HD and Ultra HD formats! Micro Converter BiDirectional SDI/HDMI 12G has all you need to convert HDMI consumer gear to SDI. Use the input to convert HDMI computers or consumer cameras into 12G-SDI, while using the output for monitoring with big screen televisions or projectors! The all metal durable design is perfect for live production and broadcast. Plus it’s small enough to be hidden and used anywhere. It can be powered from any USB-C socket, or with the included power supply and international socket adapters!
Features
Bidirectional Format Conversion
You can convert SDI to HDMI and HDMI to SDI in all SD, HD, and UHD formats up to 2160p60. Each conversion direction can be a different SD, HD, or UHD video standard, so it's like getting two converters in one.
Compact, Rugged Design
- Robust metal housing and rugged connectors.
- USB Type-C port for powering via a compatible component like a monitor or laptop.
- Updatable via the USB Type-C port and your Mac or PC.
Simultaneous Conversion
- Use the bidirectional Micro Converter to convert HDMI to 3G-SDI and 3G-SDI to HDMI simultaneously.
- Ideal for connecting HDMI consumer components to professional 3G-SDI equipment.
HDMI Camera Control
- Camera control conversion for the HDMI-output BMPCC 4K or 6K, enables use with an SDI-based live switcher.
- SDI & HDMI Timecode
- HD and SD timecode support.
- Converts HDMI timecode to SDI and vice versa.
SDI Re-Clocking
- Built-in re-clocking on 3G-SDI output enables stable output over longer cable runs.
- Compatible with SMPTE 259M/292M/296M/424M/425M level A and B.
Wider Resolution Support
- SDI support from NTSC and PAL up to DCI 2Kp60.
- HDMI support from NTSC and PAL up to 1080p60.
Embedded Audio
- Supports embedded SDI and HDMI input and output.
- LED Indicators
- LED indicators for video and power signals.
Versatile Power Options
- Power from a monitor, laptop, or other component using the USB Type-C port.
- Power supply and international plug adapter set are included
