  • Shure SLXD35 Camera Wireless Plug-On Set

Shure SLXD35 Camera Wireless Plug-On Set

Shure
  • ₱48,900.00

  • In Stock


  • 0% 3mos BDO, BPI, UNIONBANK, HSBC ₱16,300.00/mo.

Product Highlights
  • Journalism, Content Creation, Videos
  • Durable, Ergonomic Bodypack Transmitter
  • Includes Plug-On XLR Transmitter
  • 1-Channel Receiver for Camera or Bag Use
  • 118 dB Dynamic Range, 24-Bit Audio
  • Reliable Predictive-Diversity Antennas
  • 44 MHz Bandwidth, 1760 Frequencies
  • Multi-Mic Mode for Complex Setups
Quantity

Receiver

Approx. Battery Life 5.5 Hours
Audio I/O 1x 1/8" / 3.5 mm TRS Female Balanced Mic/Line Output (Locking), 1x 1/8" / 3.5 mm TRS Female Unbalanced Headphone Output
Battery Type 2x AA (Included), 1x Shure SB903 (Not Included)
Dimensions 2.7 x 4.2 x 1" / 68 x 107 x 25.3 mm
Display & Indicators OLED (AF Level, Battery Status, Channel, Frequency, Group, Menu Navigation, Metering, Multifunction, Output Level, RF Level, Sync, Transmitter Battery Status)
Mounting Options Shoe-Mount (with Included Hardware)
Number of Audio Channels 1
Power Requirements Battery, Bus Power (USB)
Receiver Type Camera-Mount
USB/Lightning Connectivity 1x USB-C Female (Bus Power, Charging)
Weight 0.4 lb / 182 g

System

Included Transmitters 1x Plug-On
Max Operating Range 328' / 100 m
Sample Rate/Resolution 24-Bit
Wireless Technology Digital UHF

Transmitter

Antenna Internal
Approx. Battery Life 8 Hours (Lithium Shure SB903)
Battery Charging Time 1.25 to 5.5 Hours
Battery Type 2x AA (Included), 1x Shure SB903 (Not Included)
Dimensions 1.6 x 5 x 1.6" / 41 x 126 x 41 mm
Display & Indicators OLED (Battery Status, Channel, Group)
Muting Off/On Switch
Power Requirements Battery
Transmitter Type Plug-On
Weight 7.1 oz / 200 g

General

In The Box 1 SLXD3 Digital Wireless Plug-On Transmitter, 1 SLXD5 Single-Channel Portable Digital Wireless Receiver. 2 Zippered Carrying Pouches, 1 Leather Protective Sleeve with Integrated Belt Clip, 1 WA311 Non-Conductive Cold Shoe Mount Adapter, 4 AA Alkaline Batteries

The Shure SLXD35 offers videographers, journalists, documentary makers, and content producers a reliable wireless plug-on transmitter system that delivers crystal-clear digital sound quality while also being quick and easy to set up, even if you're using multiple mics on set. Built around a rugged, single-channel receiver that can be camera-mounted or used in an audio bag, the system offers a comprehensive feature set that ensures professional-sounding, broadcast-ready results for demanding news gatherers and creators. This configuration includes a handheld plug-on transmitter with a locking connector that will accommodate any XLR microphone of your choice (available separately).

Transparent Digital Sound, Dependable Performance, and Multi-Mic Mode

  • The SLX-D delivers 24-bit digital audio with a fast transient response, a 20 Hz to 20 kHz frequency response, and a 118 dB dynamic range, resulting in clear, accurate sound.
  • Operating far away from potential Wi-Fi interference in the 2.4 GHz band, this configuration of the system transmits in the G58: 470 to 514 MHz UHF band, with a 44 MHz tuning range and 1760 frequencies it can autoscan to ensure a clean wireless signal.
  • Digital Predictive Switching Diversity uses a microprocessor to switch between the two antennas before dropouts occur.
  • A low latency of 3.2 ms helps ensure your sound and picture are easy to properly sync.
  • The SLX-D's spectrum-efficient digital transmission technology allows for up to 32 mics to be used at once.
  • Great for shoots with several cameras and microphones, Multi-Mic Mode lets you scan and create a list of clean frequencies, which you can send to multiple receivers via IR.
  • Each receiver will sync to the appropriate transmitter at the touch of a button; settings on the transmitters like the input gain and high-pass filter are also recalled.
  • Multi-Mic Mode makes channel allocation easier and more efficient since the receivers aren’t all auto scanning and competing for open frequencies.

Plug-On Transmitter

  • This configuration includes the SLXD3 plug-on transmitter with a secure, twist-locking XLR connector to accommodate a huge variety of microphone options, including handhelds and shotguns (available separately).
  • The transmitter offers 12 and 48V phantom power options for condenser microphones.
  • The SLXD3 features a -12 dB pad for use on loud sources and a +12 dB boost option for use on low-level sources.
  • Use the mic offset gain function to fine-tune the input gain and ensure multiple mics are at similar volume levels.
  • Engage the 150 Hz high-pass filter to reduce distracting, unwanted low-end for clearer speech.
  • The rugged, all-metal transmitter features an OLED screen that shows essential information and includes a leather case with a belt clip.
  • The system provides a transmission range up to 330'. A selectable 1/10/30mW RF output allows you to increase the transmission power to maximize the distance or to overcome interference, if necessary.
  • Two AA batteries or an SB903 rechargeable battery (available separately) will power the unit for up to 8 hours.

Rugged Receiver Ready for Camera or Audio Bag

  • Powerful and portable, the SLXD5 is a single-channel digital wireless receiver for on-camera cold shoe mounting and audio bag use featuring user-configurable front-panel controls and a bright OLED screen for key system function readouts and remaining battery life.
  • Housed in a tough metal chassis with adjustable front-mounted antennas, the SLXD5 is a great fit for on-the-go shooting rigs.
  • It offers adjustable gain control and dual 3.5mm outputs including a headphone monitor out and switchable line/mic output. Additional features include automatic frequency scanning and IR sync to easily link the transmitter and receiver to the same frequency.
  • Two AA batteries or an SB903 rechargeable battery (available separately) will power the unit for up to 5.5 hours.

Optional Rechargeable Battery Management

  • Adding the SB903 lithium-ion rechargeable battery, along with an SBC10-903 single charger, SBC203 dual-docking charger, or SBC80-903 8-bay charger offers a cost-effective and environmentally friendly alternative to throwing away AA batteries (batteries and chargers available separately).
  • Using the SB903 battery and SBC203 charger simplifies the task of keeping multiple transmitters charged and ready—you can even recharge the battery while still in the transmitter or receiver.
  • When powered by an SB903, the transmitter and receiver both display the remaining battery life in hours and minutes.
  • For bag use, the SBC-DC-903 battery eliminator (available separately) allows you to power the receiver from your mixer's battery.
  • USB-C ports on the transmitter and receiver allow for battery recharging and direct powering.

A Variety of Mics and Transmitters Available

  • Shure offers numerous lavalier, headset, and handheld microphone options to adapt your SLX-D system as your needs evolve.
  • The SLXD3 works with just about any XLR microphone on the market including Shure's VP64A and SM63L handheld mics as well as the VP89 shotgun.
  • The SLXD1 is a rugged bodypack transmitter featuring a TA4M connector to accommodate a wide range of lavalier and headset mic options.
  • The WL183 omnidirectional lavalier mic offers consistent pickup, even when the talent turns away from the mic.
  • The WL185 cardioid lavalier mic provides a directional pickup pattern for less background sound.
  • The WL184 supercardioid lavalier mic offers a very narrow, feedback-resistant pickup pattern for louder events.
  • The discrete UL4 UniPlex subminiature cardioid lav provides directional pickup, exceptional clarity, and a discreet, low-profile appearance.
  • If you need a waterproof option, the DL4 DuraPlex miniature lavalier features an IP57 rating for water and dust resistance. Its forgiving omnidirectional microphone capsule delivers a clear, transparent, full-range sound.
  • The SLXD2 handheld transmitter is available with several mic capsules choices for presenters who prefer the flexibility of a handheld microphone.
