Blackmagic Micro Converter HDMI to SDI 3G

Blackmagic
  • ₱4,000.00



Product Highlights
  • 1 x HDMI Input, 2 x SD/HD/3G-SDI Outputs
  • Selectable SD/HD Level A/B SDI Ports
  • Supports up to 1080p60 Resolution I/O
  • USB Power/SDI Re-Clocking/Timecode
  • Automatic Input Signal Detection
  • Compact, Rugged Design
  • Embedded Audio
  • LED Video & Power Signal Indicators
Quantity
Other Options

Environment

Operating Temperature 32 to 72°F / 0 to 40°C
Storage Temperature -4 to 140°F / -20 to 60°C

Hardware

OS Compatibility macOS 10.14.15 or Later, Windows 10

Input

Input Video Format HDMI (8/10-Bit 4:2:2 RGB, YUV), 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps, 1080i 50/59.94/60 fps, 720p 50/59.94/60 fps, 480i / 525 lines 29.97 fps, 576i / 625 lines 25 fps
Video Inputs 1x HDMI (2.0)

Inputs / Outputs

Audio Inputs No
Audio Outputs No
Embedded Audio HDMI/SDI
Other I/O 1x USB-C Input
Power I/O 1x USB-C (4.4 to 5.2 VDC) Input

Output

Output Video Format SDI (8/10-Bit 4:2:2 RGB, YUV), DCI 2K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps, DCI 2KPsF 25/29.97/30 fps, 1080p,, 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps, 1080PsF 25/29.97/30 fps, 1080i 50/59.94/60 fps, 720p 50/59.94/60 fps, 480i / 525 lines 29.97 fps, 576i / 625 lines 25 fps
Video Outputs 2x BNC (3G-SDI)

Power & I/O

Power Consumption 2 W

General

Dimension 3.01 x 1.8 x 0.98" / 76.45 x 45.7 x 24.89 mm
Weight 5.29 oz / 150 g

Super compact and rugged, the Micro Converter HDMI to SDI 3G from Blackmagic Design enables you to link HDMI cameras or computers to pro-style SDI (BNC) monitors or components. You can also use several units to extend HDMI over long distances using SDI cable. This compact converter has one HDMI input and two 3G-SD/HD/SDI outputs that can be set to Level A or B. It auto-detects and matches your HDMI input to the SDI output and is compatible with input/output resolutions up to 1080p60. The Micro Converter HDMI to SDI 3G features HDMI timecode support, SDI re-clocking for stability over long cable runs, and support for a wide range of pro broadcast resolutions including cine-style 48 fps.

This pocket-sized converter features a sturdy metal housing with power and signal LED status indicators and rugged connector interfaces. A USB Type-C port enables the HDMI to SDI 3G converter to easily connect to and be powered by large-screen monitors, laptops, desktop computers, or projectors. You can also power this converter using a separately available 100-240 VAC power supply, complete with four international socket adapters.

Features

Dual SDI Outputs

  • One HDMI input
  • Two 3G-SDI outputs
  • Selectable A and B level formats

Compact, Rugged Design

  • Robust metal housing and rugged connectors
  • USB Type-C port for powering via a compatible component like a monitor or laptop
  • Updatable via the USB Type-C port and your Mac or PC

SDI & HDMI Timecode

  • HD and SD timecode support
  • Converts HDMI timecode to SDI

SDI Re-Clocking

  • Built-in re-clocking on 3G-SDI output enables stable output over longer cable runs
  • Compatible with SMPTE 259M/292M/296M/424M/425M level A and B

Wider Resolution Support

  • SDI support from NTSC and PAL up to DCI 2Kp60
  • HDMI support from NTSC and PAL up to 1080p60

Embedded Audio

  • Supports embedded HDMI input and embedded SDI output

LED Indicators

  • LED indicators for video and power signals

Versatile Power Options

  • Power from a monitor, laptop, or other component using the USB Type-C port
  • Separately available 100-240 AC power supply with four socket adapters
