Blackmagic Micro Converter SDI to HDMI 3G

Blackmagic
  • ₱4,300.00



Product Highlights
  • 1x SD/HD/3G-SDI Input & 1 x Loop Output
  • 1 x HDMI Type A Output
  • DCI 2K SDI In/Out | 1080p60 HDMI Out
  • 3D LUT for Calibrating or Loop Output
  • SDI A/B Selection | USB Power
  • Embedded Audio
  • Compact, Rugged Design
  • LED Video & Power Signal Indicators
Quantity
Other Options

Control

Tally Light Yes

Environment

Operating Temperature 32 to 72°F / 0 to 40°C
Storage Temperature -4 to 140°F / -20 to 60°C

Hardware

OS Compatibility macOS 10.14.15 or Later, Windows 10

Input

Input Video Format SDI (8/10-Bit 4:2:2 RGB, YUV), DCI 2K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps, DCI 2KPsF 25/29.97/30 fps, 1080p, 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps, 1080PsF 25/29.97/30 fps, 1080i 50/59.94/60 fps, 720p 50/59.94/60 fps, 480i / 525 lines 59.94 fps, 576i / 625 lines 50 fps
Video Inputs 1x BNC (3G-SDI)

Inputs / Outputs

Audio Inputs No
Audio Outputs No
Other I/O 1x USB-C Input
Power I/O 1x USB-C (4.4 to 5.2 VDC) Input

Output

Output Video Format SDI (8/10-Bit 4:2:2 RGB, YUV), DCI 2K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps, DCI 2KPsF 25/29.97/30 fps, 1080p 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps, 1080PsF 25/29.97/30 fps, 1080i 50/59.94/60 fps, 720p 50/59.94/60 fps, 480i / 525 lines 29.97 fps, 576i / 625 lines 25 fps, HDMI (8/10-Bit 4:2:2 RGB, YUV), 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps, 1080i 50/59.94/60 fps, 720p 50/59.94/60 fps, 480i / 525 lines 29.97 fps, 576i / 625 lines 25 fps
Video Outputs 1x BNC (3G-SDI) (Loop Output), 1x HDMI

Power & I/O

Power Consumption 2.5 W

General

Dimension 3.01 x 1.8 x 0.98" / 76.45 x 45.7 x 24.89 mm
Weight 5.29 oz / 150 g
In The Box Blackmagic Design Micro Converter SDI to HDMI 3G

Super compact and rugged, the Micro Converter SDI to HDMI 3G from Blackmagic Design enables you to use HDMI-input monitors and televisions for production monitoring. This compact converter has one SD/HD/3G-SDI input, one HDMI output, and one SD/HD/3G-SDI loop output. It includes a 17-point 3D LUT that can be used to calibrate HDMI- or SDI-input monitors and it can output a LUT for viewing via the SDI loop output. The Micro Converter SDI to HDMI 3G also features automatic SD, HD, and Level A and B SDI detection and support for a wide range of pro broadcast resolutions including cine-style 48 fps.

This pocket-sized converter features a sturdy metal housing with power and signal LED status indicators and rugged connector interfaces. A USB Type-C port enables the SDI to HDMI 3G converter to easily connect to and be powered by large-screen monitors, laptops, desktop computers, or projectors. You can also power this converter using the separately available 100-240 VAC power supply, complete with four international socket adapters.

Features

HDMI & SDI Outputs

  • One SD/HD/3G-SDI input
  • One HDMI output and one SD/HD/3G-SDI loop output

Compact, Rugged Design

  • Robust metal housing and rugged connectors
  • USB Type-C port for powering via a compatible component like a monitor or laptop
  • Updatable via the USB Type-C port and your Mac or PC

3D LUT Support

  • Supports a 7-point 3D LUT for color calibrating your monitor, television, or projector
  • Outputs LUT for monitoring via SDI loop output

Wider Resolution Support

  • SDI support up to DCI 2Kp60
  • HDMI support up to 1080p60

Embedded Audio

  • Supports embedded HDMI input and embedded SDI output

LED Indicators

  • LED indicators for video and power signals

Versatile Power Options

  • Power from a monitor, laptop, or other component using the USB Type-C port
  • Separately available 100-240 AC power supply with four socket adapters
